The Fluiten PC3 015 U41U41DEE is part of the PC3 group and is designed for 15 mm shaft applications. It features a Silicon Carbide (SIC) rotary face paired with a Silicon Carbide (SIC) stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the Qseals 2C-QPS03ST61-0150-SSE.
| Brand | Fluiten |
|---|---|
| Group | PC3 |
| SKU | PC3 015 U41U41DEE |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | PARALLEL SPRING |
|---|---|
| Shaft size (D1) | 15 mm |
| Rotary face | Silicon Carbide (SIC) |
| Stationary face | Silicon Carbide (SIC) |
| Elastomers | EPDM (EPR) |
| Temperature Limit | 140 °C |
| Pressure Limit | 25 bar |
Other size or material combination?
Search within the Fluiten PC3 product group.
Alternatives
These products are direct 1-to-1 replacements for the Fluiten PC3 015 U41U41DEE, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2C-QPS03ST61-0150-SSE |
