The Fluiten S3 025 SZ31GEE LH is part of the S3 group and is designed for 25 mm shaft applications. It features a stainless steel rotary face paired with a carbon stationary face. This product uses NBR (NITRILE) elastomers. The maximum recommended operating temperature is 120°C. It is a compatible alternative to the Qseals 2C-QCS07ST01-0250-XCN-L.
| Brand | Fluiten |
|---|---|
| Group | S3 |
| SKU | S3 025 SZ31GEE LH |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | CONICAL SPRING |
|---|---|
| Shaft size | 25 mm |
| Rotary face | Stainless Steel |
| Stationary face | Carbon |
| Elastomers | NBR |
| Spring direction | Left |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 120 °C |
| Pressure Limit | 20 bar |
Alternatives
These products are direct 1-to-1 replacements for the Fluiten S3 025 SZ31GEE LH, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2C-QCS07ST01-0250-XCN-L |
