The Grundfos 96433686 (DQQV) is part of the None group and is designed for 38 mm shaft applications. It features a silicon carbide rotary face paired with a silicon carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It is a compatible alternative to the Qseals 2C-QMS02ST46-0380-SSV.
| Brand | Grundfos |
|---|---|
| Group | None |
| SKU | 96433686 (DQQV) |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | MULTI SPRING |
|---|---|
| Shaft size | 38 mm |
| Rotary face | Silicon Carbide |
| Stationary face | Silicon Carbide |
| Elastomers | Viton |
| Stationary Housing Diameter | |
| Stationary Bore Depth | |
| Temperature Limit | 205 °C |
| Pressure Limit | 25 bar |
Alternatives
These products are direct 1-to-1 replacements for the Grundfos 96433686 (DQQV), with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2C-QMS02ST46-0380-SSV |
