The Flygt 433 74 01 is part of the None group and is designed for 120 mm shaft applications. It features a tungsten carbide rotary face paired with a tungsten carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It is a compatible alternative to the Qseals 2C-QFLYGT3120STS-1200-TTV-TCV.
| Brand | Flygt |
|---|---|
| Group | None |
| SKU | 433 74 01 |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size | 120 mm |
| Rotary face | Tungsten Carbide |
| Stationary face | Tungsten Carbide |
| Elastomers | Viton |
| Outer rotary face | Tungsten Carbide |
| Outer stationary face | Carbon |
| Outer elastomer | Viton |
| Temperature Limit | 205 °C |
| Pressure Limit | 20 bar |
Alternatives
These products are direct 1-to-1 replacements for the Flygt 433 74 01, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2C-QFLYGT3120STS-1200-TTV-TCV |
