The Qseals 2C-QFLYGT3120STS-1200-TTV-TCV is part of the QFLYGT3120STS group and is designed for 120 mm shaft applications. It features a Tungsten Carbide (TC) rotary face paired with a Tungsten Carbide (TC) stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It serves as a direct replacement for the AES N-T05VC-GGZGAZ1-1200, Flygt 397 09 00, Flygt 433 74 01, and 2 other alternatives.
| Brand | Qseals |
|---|---|
| Group | QFLYGT3120STS |
| SKU | 2C-QFLYGT3120STS-1200-TTV-TCV |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size (D1) | 120 mm |
| Rotary face | Tungsten Carbide (TC) |
| Stationary face | Tungsten Carbide (TC) |
| Elastomers | Viton (FKM VIT) |
| Outer rotary face | Tungsten Carbide (TC) |
| Outer stationary face | Carbon (CAR) |
| Outer elastomer | Viton |
| Temperature Limit | 205 °C |
| Pressure Limit | 20 bar |
Other size or material combination?
Search within the Qseals QFLYGT3120STS product group.
