The Grundfos 96066757 is part of the None group and is designed for 16 mm shaft applications. It features a silicon carbide rotary face paired with a silicon carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It is a compatible alternative to the Qseals 1C-QSARLS16-0160-SSV-SCV.
| Brand | Grundfos |
|---|---|
| Group | None |
| SKU | 96066757 |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size | 16 mm |
| Rotary face | Silicon Carbide |
| Stationary face | Silicon Carbide |
| Elastomers | Viton |
| Outer rotary face | Silicon Carbide |
| Outer stationary face | Carbon |
| Outer elastomer | Viton |
| Temperature Limit | 205 °C |
| Pressure Limit | 20 bar |
Alternatives
These products are direct 1-to-1 replacements for the Grundfos 96066757, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 1C-QSARLS16-0160-SSV-SCV |
