The Qseals 1C-QCSF8-0350A-ZZE is part of the QCSF8 group and is designed for 35 mm shaft applications. It features a sintered silicon carbide rotary face paired with a sintered silicon carbide stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES F-T01FZU-JJYM-0350A and Fristam Part No 0816330193.
| Brand | Qseals |
|---|---|
| Group | QCSF8 |
| SKU | 1C-QCSF8-0350A-ZZE |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size | 35 mm |
| Rotary face | Sintered Silicon Carbide |
| Stationary face | Sintered Silicon Carbide |
| Elastomers | EPDM |
| Temperature Limit | 140 °C |
| Pressure Limit | 20 bar |
Alternatives
The Qseals 1C-QCSF8-0350A-ZZE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-T01FZU-JJYM-0350A |
| Fristam | Part No 0816330193 |
