The Qseals 1C-QRB15ST09-0530-CSN is part of the QRB15ST09 group and is designed for 53 mm shaft applications. It features a carbon rotary face paired with a silicon carbide stationary face. This product uses NBR (NITRILE) elastomers. The maximum recommended operating temperature is 120°C. It serves as a direct replacement for the AES F-B02D-ADY1-0530, AES F-B09DU-ADX1-0530, and Vulcan 0530.19C.N.D..
| Brand | Qseals |
|---|---|
| Group | QRB15ST09 |
| SKU | 1C-QRB15ST09-0530-CSN |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size | 53 mm |
| Rotary face | Carbon |
| Stationary face | Silicon Carbide |
| Elastomers | NBR |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 120 °C |
| Pressure Limit | 20 bar |
Alternatives
The Qseals 1C-QRB15ST09-0530-CSN is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-B02D-ADY1-0530 |
| AES | F-B09DU-ADX1-0530 |
| Vulcan | 0530.19C.N.D. |
Applications
The Qseals 1C-QRB15ST09-0530-CSN can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Alfa Laval | ALC-3D 5.5kw-18.5kw |
