The Qseals 1C-QRB15ST09-0600-CSE is part of the QRB15ST09 group and is designed for 60 mm shaft applications. It features a Carbon (CAR) rotary face paired with a Silicon Carbide (SIC) stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES F-B02D-ADY1-0600, AES F-B09DU-ADY1-0600, LATTY LI-10116, and 2 other alternatives.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size (D1) | 60 mm |
| Rotary face | Carbon (CAR) |
| Stationary face | Silicon Carbide (SIC) |
| Elastomers | EPDM (EPR) |
| Rotary Outer Diameter (D3) | |
| Stationary Housing Diameter (D7) | |
| Rotary Working Length (L1) | |
| Stationary Bore Depth (L4) | |
| Temperature limit | 140 °C |
| Pressure limit | 20 bar |
Other size or material combination?
Search within the Qseals QRB15ST09 product group.
Alternatives
The Qseals 1C-QRB15ST09-0600-CSE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-B02D-ADY1-0600 |
| AES | F-B09DU-ADY1-0600 |
| LATTY | LI-10116 |
| LATTY | LI AL ALC 060 B U3 EP |
| Vulcan | 0600.19C.E.D. |
Applications
The Qseals 1C-QRB15ST09-0600-CSE can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Alfa Laval | ALC-3D 22kw |
