The Qseals 1C-QRB15ST09-0600-ZZE is part of the QRB15ST09 group and is designed for 60 mm shaft applications. It features a sintered silicon carbide rotary face paired with a sintered silicon carbide stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES F-B09DU-JJY1-0600, Alfa Laval 31801-2470-6, LATTY LI-10117, and LATTY LI AL ALC 060 U3 U3 EP.
| Brand | Qseals |
|---|---|
| Group | QRB15ST09 |
| SKU | 1C-QRB15ST09-0600-ZZE |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size | 60 mm |
| Rotary face | Sintered Silicon Carbide |
| Stationary face | Sintered Silicon Carbide |
| Elastomers | EPDM |
| Stationary Housing Diameter | |
| Stationary Bore Depth | |
| Temperature Limit | 140 °C |
| Pressure Limit | 20 bar |
Alternatives
The Qseals 1C-QRB15ST09-0600-ZZE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-B09DU-JJY1-0600 |
| Alfa Laval | 31801-2470-6 |
| LATTY | LI-10117 |
| LATTY | LI AL ALC 060 U3 U3 EP |
Applications
The Qseals 1C-QRB15ST09-0600-ZZE can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Alfa Laval | ALC-3D 22kw |
| Brand | SKU |
|---|
