The Qseals 1C-QWS03D-0350-XCE-XCE is part of the QWS03D group and is designed for 35 mm shaft applications. It features a Stainless Steel (SS) rotary face paired with a Carbon (CAR) stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES F-W03DU-EAYEAYS-0350 and Alfa Laval 7400.103E/103E.
| Brand | Qseals |
|---|---|
| Group | QWS03D |
| SKU | 1C-QWS03D-0350-XCE-XCE |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | WAVE SPRING |
|---|---|
| Shaft size (D1) | 35 mm |
| Rotary face | Stainless Steel (SS) |
| Stationary face | Carbon (CAR) |
| Elastomers | EPDM (EPR) |
| Outer rotary face | Stainless Steel (SS) |
| Outer stationary face | Carbon (CAR) |
| Outer elastomer | EPDM |
| Temperature Limit | 140 °C |
| Pressure Limit | 20 bar |
Other size or material combination?
Search within the Qseals QWS03D product group.
Alternatives
The Qseals 1C-QWS03D-0350-XCE-XCE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-W03DU-EAYEAYS-0350 |
| Alfa Laval | 7400.103E/103E |
Applications
The Qseals 1C-QWS03D-0350-XCE-XCE can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Ibex (Alfa Laval) | NMOG 522 |
| SSP | SRU3 |
| Alfa Laval | NMOG 522 |
| Alfa Laval | NMOG 532 |
| Alfa Laval | SRU3 |
| Alfa Laval | SSP SRU3 |
