The Qseals 1C-QWS15STS-0254-ZZE is part of the QWS15STS group and is designed for 25.4 mm shaft applications. It features a sintered silicon carbide rotary face paired with a sintered silicon carbide stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES F-W015U-JJY1-0254 and Vulcan 0254.1651.E.S..
| Brand | Qseals |
|---|---|
| Group | QWS15STS |
| SKU | 1C-QWS15STS-0254-ZZE |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size | 25.4 mm |
| Rotary face | Sintered Silicon Carbide |
| Stationary face | Sintered Silicon Carbide |
| Elastomers | EPDM |
| Temperature Limit | 140 °C |
| Pressure Limit | 16 bar |
Alternatives
The Qseals 1C-QWS15STS-0254-ZZE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-W015U-JJY1-0254 |
| Vulcan | 0254.1651.E.S. |
Applications
The Qseals 1C-QWS15STS-0254-ZZE can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Tuchenhagen | VPSH 42 |
| Tuchenhagen | VPSU 42 |
| Jabsco | Hy~Line LH42 |
| Brand | SKU |
|---|---|
| Jabsco | Hy~Line LH44 |
| Jabsco | Ultima LU42 |
| Jabsco | Ultima LU44 |
