The Qseals 2C-QCS03ST09-0200-SSE-L is part of the QCS03ST09 group and is designed for 20 mm shaft applications. It features a silicon carbide rotary face paired with a silicon carbide stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES N-T01DBU-DDYL-0240, Burgmann H12N/20-00-L Q1Q1EGG, Burgmann H177GN/20-00-L Q1Q1EGG, and 2 other alternatives.
| Brand | Qseals |
|---|---|
| Group | QCS03ST09 |
| SKU | 2C-QCS03ST09-0200-SSE-L |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | CONICAL SPRING |
|---|---|
| Shaft size | 20 mm |
| Rotary face | Silicon Carbide |
| Stationary face | Silicon Carbide |
| Elastomers | EPDM |
| Spring direction | Left |
| Upper Shaftsize | |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 140 °C |
| Pressure Limit | 55 bar |
Alternatives
The Qseals 2C-QCS03ST09-0200-SSE-L is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-T01DBU-DDYL-0240 |
| Burgmann | H12N/20-00-L Q1Q1EGG |
| Burgmann | H177GN/20-00-L Q1Q1EGG |
| Burgmann | H17GN/20-00-L Q1Q1EGG |
| Vulcan | 0240.82.L.E.S. |
