The Qseals 2C-QCS07ST01-0750-UCE-R is part of the QCS07ST01 group and is designed for 75 mm shaft applications. It features a ceramic rotary face paired with a carbon stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES N-T03U-BAYR-0750 and Fluiten S3 075 CZ31DEE RH.
| Brand | Qseals |
|---|---|
| Group | QCS07ST01 |
| SKU | 2C-QCS07ST01-0750-UCE-R |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | CONICAL SPRING |
|---|---|
| Shaft size | 75 mm |
| Rotary face | Ceramic |
| Stationary face | Carbon |
| Elastomers | EPDM |
| Spring direction | Right |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 140 °C |
| Pressure Limit | 20 bar |
Alternatives
The Qseals 2C-QCS07ST01-0750-UCE-R is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-T03U-BAYR-0750 |
| Fluiten | S3 075 CZ31DEE RH |
