The Qseals 2C-QCS11ST02-0330-SSE-R is part of the QCS11ST02 group and is designed for 33 mm shaft applications. It features a silicon carbide rotary face paired with a silicon carbide stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES N-T04D-DDYR-0330, LATTY 534 033 U3 U3 E RH, Lowara 0022 333 03, and Vulcan 0330.13DIN.R.E.S..
| Brand | Qseals |
|---|---|
| Group | QCS11ST02 |
| SKU | 2C-QCS11ST02-0330-SSE-R |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | CONICAL SPRING |
|---|---|
| Shaft size | 33 mm |
| Rotary face | Silicon Carbide |
| Stationary face | Silicon Carbide |
| Elastomers | EPDM |
| Spring direction | Right |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 140 °C |
| Pressure Limit | 16 bar |
Alternatives
The Qseals 2C-QCS11ST02-0330-SSE-R is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-T04D-DDYR-0330 |
| LATTY | 534 033 U3 U3 E RH |
| Lowara | 0022 333 03 |
| Vulcan | 0330.13DIN.R.E.S. |
Applications
The Qseals 2C-QCS11ST02-0330-SSE-R can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
