The Qseals 2C-QMS01ST46-0530-SSKP is part of the QMS01ST46 group and is designed for 53 mm shaft applications. It features a Silicon Carbide (SIC) rotary face paired with a Silicon Carbide (SIC) stationary face. This product uses Kalrez (FFKM) elastomers. The maximum recommended operating temperature is 205°C.
Technical specifications
| Category | MULTI SPRING |
|---|---|
| Shaft size (D1) | 53 mm |
| Rotary face | Silicon Carbide (SIC) |
| Stationary face | Silicon Carbide (SIC) |
| Elastomers | Kalrez (FFKM) |
| Outer elastomer | PTFE (PTFE) |
| Temperature limit | 205 °C |
| Pressure limit | 25 bar |
Other size or material combination?
Search within the Qseals QMS01ST46 product group.
