The Qseals 2C-QMS02ST46-0350-TTV is part of the QMS02ST46 group and is designed for 35 mm shaft applications. It features a tungsten carbide rotary face paired with a tungsten carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It serves as a direct replacement for the Fluiten TB035 K22K22VE9E and Fluiten TBHA035 K21K22VEE.
| Brand | Qseals |
|---|---|
| Group | QMS02ST46 |
| SKU | 2C-QMS02ST46-0350-TTV |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | MULTI SPRING |
|---|---|
| Shaft size | 35 mm |
| Rotary face | Tungsten Carbide |
| Stationary face | Tungsten Carbide |
| Elastomers | Viton |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 205 °C |
| Pressure Limit | 25 bar |
Alternatives
The Qseals 2C-QMS02ST46-0350-TTV is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| Fluiten | TB035 K22K22VE9E |
| Fluiten | TBHA035 K21K22VEE |
