The Qseals 2C-QMS02ST46-1100-SSV is part of the QMS02ST46 group and is designed for 110 mm shaft applications. It features a silicon carbide rotary face paired with a silicon carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It serves as a direct replacement for the Burgmann HJ92N/110-G46 Q1Q1VGG, Burgmann HJ977GN/110-G46 Q1Q1VGG, and Fluiten TBHA0110 U32U31VEE.
| Brand | Qseals |
|---|---|
| Group | QMS02ST46 |
| SKU | 2C-QMS02ST46-1100-SSV |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | MULTI SPRING |
|---|---|
| Shaft size | 110 mm |
| Rotary face | Silicon Carbide |
| Stationary face | Silicon Carbide |
| Elastomers | Viton |
| Temperature Limit | 205 °C |
| Pressure Limit | 25 bar |
Alternatives
The Qseals 2C-QMS02ST46-1100-SSV is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| Burgmann | HJ92N/110-G46 Q1Q1VGG |
| Burgmann | HJ977GN/110-G46 Q1Q1VGG |
| Fluiten | TBHA0110 U32U31VEE |
