The Qseals 2C-QPS02ST50-0110-CSV is part of the QPS02ST50 group and is designed for 11 mm shaft applications. It features a carbon rotary face paired with a silicon carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It serves as a direct replacement for the AES N-P02-ADZ1-0110, Burgmann MG920/11-G50 BQ1VFF, Burgmann MG920/11-G50 BQ1VGG, and 2 other alternatives.
| Brand | Qseals |
|---|---|
| Group | QPS02ST50 |
| SKU | 2C-QPS02ST50-0110-CSV |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PARALLEL SPRING |
|---|---|
| Shaft size | 11 mm |
| Rotary face | Carbon |
| Stationary face | Silicon Carbide |
| Elastomers | Viton |
| Temperature Limit | 205 °C |
| Pressure Limit | 16 bar |
Alternatives
The Qseals 2C-QPS02ST50-0110-CSV is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-P02-ADZ1-0110 |
| Burgmann | MG920/11-G50 BQ1VFF |
| Burgmann | MG920/11-G50 BQ1VGG |
| None | 513 011 B U3 V |
| Sealol | 043-BFC-SEF-011 |
