The Qseals 2C-QPS04STWA-0349-CUV is part of the QPS04STWA group and is designed for 34.9 mm shaft applications. It features a Carbon (CAR) rotary face paired with a Ceramic (CER) stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It serves as a direct replacement for the AES N-P04-ABZ2-0349, US Seal PS-177V, and US Seal PS-6775V.
| Brand | Qseals |
|---|---|
| Group | QPS04STWA |
| SKU | 2C-QPS04STWA-0349-CUV |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | PARALLEL SPRING |
|---|---|
| Shaft size (D1) | 34.9 mm |
| Rotary face | Carbon (CAR) |
| Stationary face | Ceramic (CER) |
| Elastomers | Viton (FKM VIT) |
| Stationary Housing Diameter (D7) | |
| Stationary Bore Depth (L4) | |
| Temperature Limit | 205 °C |
| Pressure Limit | 25 bar |
Other size or material combination?
Search within the Qseals QPS04STWA product group.
Alternatives
The Qseals 2C-QPS04STWA-0349-CUV is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-P04-ABZ2-0349 |
| US Seal | PS-177V |
| US Seal | PS-6775V |
Applications
The Qseals 2C-QPS04STWA-0349-CUV can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Worthington | Frame 2 D-1012 |
| Worthington | Frame 2 D-1020 |
| Worthington | Frame 2 D-812 |
| Worthington | Frame 2 D-820 |
