The Qseals 2C-QPS04STWA-0412-CUV is part of the QPS04STWA group and is designed for 41.2 mm shaft applications. It features a carbon rotary face paired with a ceramic stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It is a compatible alternative to the AES N-P04-ABZ2-0412. It can be installed in equipment such as the Stalker 100HL, Stalker 100HL / HD, Stalker 100SHL, and 6 other applications.
| Brand | Qseals |
|---|---|
| Group | QPS04STWA |
| SKU | 2C-QPS04STWA-0412-CUV |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PARALLEL SPRING |
|---|---|
| Shaft size | 41.2 mm |
| Rotary face | Carbon |
| Stationary face | Ceramic |
| Elastomers | Viton |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 205 °C |
| Pressure Limit | 25 bar |
Alternatives
The Qseals 2C-QPS04STWA-0412-CUV is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-P04-ABZ2-0412 |
Applications
The Qseals 2C-QPS04STWA-0412-CUV can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
