The Qseals 2C-QPS16ST50-0508-SSN is part of the QPS16ST50 group and is designed for 50.8 mm shaft applications. It features a silicon carbide rotary face paired with a silicon carbide stationary face. This product uses NBR (NITRILE) elastomers. The maximum recommended operating temperature is 120°C. It serves as a direct replacement for the AES N-P02U-DDX1-0508 and Vulcan 0508.A2.N.S..
| Brand | Qseals |
|---|---|
| Group | QPS16ST50 |
| SKU | 2C-QPS16ST50-0508-SSN |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PARALLEL SPRING |
|---|---|
| Shaft size | 50.8 mm |
| Rotary face | Silicon Carbide |
| Stationary face | Silicon Carbide |
| Elastomers | NBR |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 120 °C |
| Pressure Limit | 25 bar |
Alternatives
The Qseals 2C-QPS16ST50-0508-SSN is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-P02U-DDX1-0508 |
| Vulcan | 0508.A2.N.S. |
Applications
The Qseals 2C-QPS16ST50-0508-SSN can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
