The Qseals 2C-QRB24STS-0500-CSE is part of the QRB24STS group and is designed for 50 mm shaft applications. It features a Carbon (CAR) rotary face paired with a Silicon Carbide (SIC) stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the AES N-B09XSU-ADY1-0500.
| Brand | Qseals |
|---|---|
| Group | QRB24STS |
| SKU | 2C-QRB24STS-0500-CSE |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | RUBBER BELLOW |
|---|---|
| Shaft size (D1) | 50 mm |
| Rotary face | Carbon (CAR) |
| Stationary face | Silicon Carbide (SIC) |
| Elastomers | EPDM (EPR) |
| Temperature Limit | 140 °C |
Other size or material combination?
Search within the Qseals QRB24STS product group.
Alternatives
The Qseals 2C-QRB24STS-0500-CSE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-B09XSU-ADY1-0500 |
Applications
The Qseals 2C-QRB24STS-0500-CSE can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Fristam Pumpen | FZ 25KF |
