The Qseals 2C-QWS03D-0350-TTV-XCV is part of the QWS03D group and is designed for 35 mm shaft applications. It features a tungsten carbide rotary face paired with a tungsten carbide stationary face. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It serves as a direct replacement for the AES F-W03DU-GGZEAZS-0350 and Alfa Laval 7400.173V/173V.
| Brand | Qseals |
|---|---|
| Group | QWS03D |
| SKU | 2C-QWS03D-0350-TTV-XCV |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | WAVE SPRING |
|---|---|
| Shaft size | 35 mm |
| Rotary face | Tungsten Carbide |
| Stationary face | Tungsten Carbide |
| Elastomers | Viton |
| Outer rotary face | Stainless Steel |
| Outer stationary face | Carbon |
| Outer elastomer | Viton |
| Temperature Limit | 205 °C |
Alternatives
The Qseals 2C-QWS03D-0350-TTV-XCV is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | F-W03DU-GGZEAZS-0350 |
| Alfa Laval | 7400.173V/173V |
Applications
The Qseals 2C-QWS03D-0350-TTV-XCV can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
| Brand | SKU |
|---|---|
| Ibex (Alfa Laval) | NMOG 522 |
| SSP | SRU3 |
| Alfa Laval | NMOG 522 |
| Brand | SKU |
|---|---|
| Alfa Laval | NMOG 532 |
| Alfa Laval | SRU3 |
| Alfa Laval | SSP SRU3 |
