The Qseals 2R-QCS11-0140-U-E-R is part of the QCS11 group and is designed for 14 mm shaft applications. It features ceramic rotary faces. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the AES N-T04D-B-YR-0140. It can be applied in 27 models of Calpeda equipment.
| Brand | Qseals |
|---|---|
| Group | QCS11 |
| SKU | 2R-QCS11-0140-U-E-R |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | CONICAL SPRING |
|---|---|
| Shaft size | 14 mm |
| Rotary face | Ceramic |
| Elastomers | EPDM |
| Spring direction | Right |
| Rotary Outer Diameter | |
| Rotary Working Length | |
| Temperature Limit | 140 °C |
| Pressure Limit | 16 bar |
Alternatives
The Qseals 2R-QCS11-0140-U-E-R is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-T04D-B-YR-0140 |
Applications
The Qseals 2R-QCS11-0140-U-E-R can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
