The Qseals 2R-QCS11-0140B-S-E-R is part of the QCS11 group and is designed for 14 mm shaft applications. It features silicon carbide rotary faces. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the Vulcan 0140B.13DIN.R.E.S.SEA.
| Brand | Qseals |
|---|---|
| Group | QCS11 |
| SKU | 2R-QCS11-0140B-S-E-R |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | CONICAL SPRING |
|---|---|
| Shaft size | 14 mm |
| Rotary face | Silicon Carbide |
| Elastomers | EPDM |
| Spring direction | Right |
| Rotary Outer Diameter | |
| Rotary Working Length | |
| Temperature Limit | 140 °C |
| Pressure Limit | 16 bar |
Alternatives
The Qseals 2R-QCS11-0140B-S-E-R is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| Vulcan | 0140B.13DIN.R.E.S.SEA |
