The Qseals 2S-ST50-0180--UE is part of the ST50 group and is designed for 18 mm shaft applications. It features ceramic stationary faces. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It serves as a direct replacement for the AES N-P02U-BYQ-0180 and Vulcan 0180.20.E.A.STAT. It is designed for use in the Pedrollo CP 200.
| Brand | Qseals |
|---|---|
| Group | ST50 |
| SKU | 2S-ST50-0180--UE |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | STATIONARY |
|---|---|
| Shaft size | 18 mm |
| Stationary face | Ceramic |
| Elastomers | EPDM |
| Stationary Housing Diameter | |
| Stationary Bore Depth | |
| Temperature Limit | 140 °C |
| Pressure Limit | 16 bar |
Alternatives
The Qseals 2S-ST50-0180--UE is a direct 1-to-1 replacement for these alternatives, with superior quality, longer service life and excellent value for money.
| Brand | SKU |
|---|---|
| AES | N-P02U-BYQ-0180 |
| Vulcan | 0180.20.E.A.STAT |
Applications
The Qseals 2S-ST50-0180--UE can be applied in the following installations and equipment, where it provides reliable sealing and optimal operational reliability.
