The Vulcan 1000.97.L.E.P. is part of the 97 group and is designed for 100 mm shaft applications. It features a stainless steel rotary face paired with a carbon stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the Qseals 2C-QPS08STSQCL3-1000-XCE-L.
| Brand | Vulcan |
|---|---|
| Group | 97 |
| SKU | 1000.97.L.E.P. |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | PARALLEL SPRING |
|---|---|
| Shaft size | 100 mm |
| Rotary face | Stainless Steel |
| Stationary face | Carbon |
| Elastomers | EPDM |
| Spring direction | L |
| Rotary Outer Diameter | |
| Stationary Housing Diameter | |
| Rotary Working Length | |
| Stationary Bore Depth | |
| Temperature Limit | 140 °C |
| Pressure Limit | 25 bar |
Alternatives
These products are direct 1-to-1 replacements for the Vulcan 1000.97.L.E.P., with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2C-QPS08STSQCL3-1000-XCE-L |
