The AES F-W03DU-EAYEAYS-0450 is part of the W03DU group and is designed for 45 mm shaft applications. It features a Stainless Steel (SS) rotary face paired with a Carbon (CAR) stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the Qseals 1C-QWS03D-0450-XCE-XCE.
Technical specifications
| Category | WAVE SPRING |
|---|---|
| Shaft size (D1) | 45 mm |
| Rotary face | Stainless Steel (SS) |
| Stationary face | Carbon (CAR) |
| Elastomers | EPDM (EPR) |
| Outer rotary face | Stainless Steel (SS) |
| Outer stationary face | Carbon (CAR) |
| Outer elastomer | EPDM (EPDM) |
| Temperature limit | 140 °C |
| Pressure limit | 20 bar |
Other size or material combination?
Search within the AES W03DU product group.
Alternatives
These products are direct 1-to-1 replacements for the AES F-W03DU-EAYEAYS-0450, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 1C-QWS03D-0450-XCE-XCE |
