The AES F-W13SU-GGY1-0698 is part of the W13SU group and is designed for 69.8 mm shaft applications. It features a Tungsten Carbide (TC) rotary face paired with a Tungsten Carbide (TC) stationary face. This product uses EPDM (EPR) elastomers. The maximum recommended operating temperature is 140°C. It is a compatible alternative to the Qseals 1C-QWS14STS-0698-TTE.
| Brand | AES |
|---|---|
| Group | W13SU |
| SKU | F-W13SU-GGY1-0698 |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | PUMP SPECIFIC |
|---|---|
| Shaft size (D1) | 69.8 mm |
| Rotary face | Tungsten Carbide (TC) |
| Stationary face | Tungsten Carbide (TC) |
| Elastomers | EPDM (EPR) |
| Temperature Limit | 140 °C |
| Pressure Limit | 16 bar |
Other size or material combination?
Search within the AES W13SU product group.
Alternatives
These products are direct 1-to-1 replacements for the AES F-W13SU-GGY1-0698, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 1C-QWS14STS-0698-TTE |
