The AES N-B01--BXQ-0150 is part of the B01 group and is designed for 15 mm shaft applications. It features Ceramic (CER) stationary faces. This product uses NBR (NITRILE) elastomers. The maximum recommended operating temperature is 120°C. It is a compatible alternative to the Qseals 2S-QRB05-0150--UN.
| Brand | AES |
|---|---|
| Group | B01 |
| SKU | N-B01--BXQ-0150 |
No commitment. Personalised offer including technical data sheet. Usually within 1–3 hours during business hours.
Technical specifications
| Category | RUBBER BELLOW |
|---|---|
| Shaft size (D1) | 15 mm |
| Stationary face | Ceramic (CER) |
| Elastomers | NBR (NITRILE) |
| Stationary Housing Diameter (D7) | |
| Stationary Bore Depth (L4) | |
| Temperature Limit | 120 °C |
| Pressure Limit | 16 bar |
Other size or material combination?
Search within the AES B01 product group.
Alternatives
These products are direct 1-to-1 replacements for the AES N-B01--BXQ-0150, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2S-QRB05-0150--UN |
