The AES N-P02U-DZQ-0508 is part of the P02U group and is designed for 50.8 mm shaft applications. It features silicon carbide stationary faces. This product uses Viton (FKM VIT) elastomers. The maximum recommended operating temperature is 205°C. It is a compatible alternative to the Qseals 2S-ST50-0508--SV.
| Brand | AES |
|---|---|
| Group | P02U |
| SKU | N-P02U-DZQ-0508 |
No commitment. Receive a price and technical data sheet within 24 hours.
Technical specifications
| Category | STATIONARY |
|---|---|
| Shaft size | 50.8 mm |
| Stationary face | Silicon Carbide |
| Elastomers | Viton |
| Stationary Housing Diameter | |
| Stationary Bore Depth | |
| Temperature Limit | 205 °C |
| Pressure Limit | 16 bar |
Alternatives
These products are direct 1-to-1 replacements for the AES N-P02U-DZQ-0508, with superior performance, longer service life and better reliability.
| Brand | SKU |
|---|---|
| Qseals | 2S-ST50-0508--SV |
